LuxxMaster Raman Boxx 785nm Laser

Raman 785nm Laser
LuxxMaster Raman Boxx 785nm Laser
Model: LML-785.OCB-03 Wavelength stabilised Laser Source

Manual and Software Key

Including manufacturers recommended Heat Sink.

This Instrument was NEW in November 2014, and only used for a single experiment.

The LuxxMaster™ LML series Compact Raman Boxx™ packages PD-LD’s award-winning LuxxMaster™ laser source
stabilized by Volume Bragg Grating® (VBG®) in a rugged box ideally suited for Raman spectroscopy
and other applications that require narrow linewidth laser source. Its small size,
turn-key operation and simple interface makes the Raman Boxx™ ideal for industrial,
military and security applications.


Performance:

•     Wavelengths: Configured 785nm (Raman)
•     Λc= ±0.5 nm
•     Line Width: 1.3 cm-1
•     Built-in Thermo Electric Cooler for Laser Temperature Control
•     Built-in Monitor Photodiode for Automatic Power Control
•     Optical Power: 500 mW

We have other Instruments for use with Raman Experiments:

Stock Reference:

J051

J052
