Envair Coalsafe Elite 12 Ducted Fume cupboard

Envair Coalsafe Elite 12 Ducted Fume cupboard

These belong to the latest generation of fume cupboards using the most innovative molecular filtration technology manufactured by Faster, in which the choice of materials of construction of the highest quality guarantees a safe working environment together with fume containment for protection from chemicals, vapours and aerosol in the laboratories.

Applications for Coalsafe fume cupboards may be found in many laboratories, including those in clinical diagnostic testing, biological and medical research, analytical chemistry, Q.C., biotechnology, pharmaceutical industries, food, fine chemical, petrochemical, cosmetic, photographic
laboratories and electronic industries.

Equipped with a microprocessor based monitoring system for a range of data which includes type and code number of the filter being used, installation date, maximum time allowance for filter use and a warning date for its replacement
Monitoring data: power on/off, light on/off, microprocessor monitoring system checking airflow, pre-filter and filter efficiency, variable speed air regulation, audible and visual alarms alert the operator to low/high airflow, fan failure, filter and pre-filter condition, black-out, gas detector and anemometer failure
External structure made by cold rolled epoxy painted galvanized for superior resistance against chemical solvents
Acid resistant PVC rear wall and work surface with special design to drive the liquids spilt in the corners of the surface
Front window: stratified hinged safety glass to give easy access to large items. It is provided with gas springs to keep it open during maintenance or sanitization operations
Motor blower: IP54 centrifugal motor fan, capable of maintaining a constant airflow by compensating for the clogging of the prefilters, which occurs during normal operation
Back side hole on the rear panel with rubber cover to plug external devices
200mm collar placed on the top of the unit for ducting connection
Lighting: fluorescent tubes in built-in housing, placed outside the working area
User-friendly practical keyboard and the rear-lit LCD will continuously display the face speed and a digital setting system to select the most suitable velocity for each specific contaminant used

Useful dimension (wxdxh) 1123x600x660
Overall dimension (wxdxh) 1185x760x1120

Serial No's 830 840 841 842

YOM:2018

Original CD manuals and documentation
